WebGPU Tech Demo

url - https://gnikoloff.github.io/webgpu-sponza-demo

code -https://github.com/gnikoloff/webgpu-sponza-demo

About

A WebGPU deferred rendering playground written as a personal project to familiarize myself better with the API and explore various rendering techniques. As WebGPU is still considered experimental browser technology certain things might break for you.

Features

• glTF loading and parsing
• Physically based shading
• Cascaded shadow mapping (2 cascades)
• Deferred Renderer (3 MRT) with culled light volumes using a stencil buffer
• 400+ dynamic light sources moved in a compute shader
• Separate forward pass for alpha masked objects (foliage)
• SSAO
• Screen Space Reflections with the ability to switch between Hi-Z and Linear raymarching
• Physically based bloom
• Temporal Anti-Aliasing (TAA)
• UI controls to tweak various different rendering parameters
• Dynamic performance degradation if the framerate dips below 60fps for longer than 2 seconds
• Mobile support

Requirements

WebGPU is still considered experimental technology and might not be implemented in the version of your browser of choice. Please refer to the WebGPU Implementation Status for more info.

Dependencies

• @loaders.gl/gltf - Loading and parsing the glTF Sponza file
• webgpu-utils - Random useful things for WebGPU
• wgpu-matrix - Fast 3d math library for webgpu
• wgsl-preprocessor - Adds simple preprocessor macros to your WGSL shader
• hdr.js - RGBE(.hdr) file reader / writer

References and Readings

• WebGPU Shadow Playground
• WebGPU Clustered Forward Shading
• SSAO
• Screen Space Reflections: Implementation and optimization – HI-Z Tracing Method
• Temporal Anti-Aliasing(TAA) Tutorial
• Physically Based Bloom
• Cascaded Shadow Mapping
• Satin - A 3D Graphics Framework built on Apple's Metal
• WebGPU Spec
• WGSL Spec
